Table
2-12

LEDs
on
the
XSCF
or
XSCF
unit
and
their
states
Name Color Status Description
READY Green On Indicates
that
the
component
is
operating.
The
component
cannot
be
released
and
removed
from
the
system.
Blinking
(*1)
Indicates
that
the
component
is
currently
being
mounted
on
the
system
or
being
disconnected
from
the
system.
Off Indicates
that
the
component
is
disconnected
from
the
system.
Indicates
that
the
component
can
be
removed
and
replaced.
CHECK Amber On Indicates
that
an
error
has
occurred.
Blinking
(*1)
Indicates
that
the
component
requires
maintenance
(This
function
is
also
referred
to
as
the
"locator").
Off Indicates
the
normal
state.
MASTER Green On Master
chassis
Off Slave
chassis
*1
The
blink
interval
is
1
second
(1
Hz).
Table
2-13

LEDs
on
the
XSCF-LAN
port
and
their
states
Name Color Status Description
ACT Green On Indicates
that
communication
is
being
performed.
Off Indicates
that
communication
is
not
being
performed.
LINK
SPEED Amber On Indicates
that
the
communication
speed
is
1
Gbps.
Green Blinking
(*1)
Indicates
that
the
communication
speed
is
100
Mbps.
Off Indicates
that
the
communication
speed
is
10
Mbps.
*1
The
blink
interval
is
1
second
(1
Hz).
Table
2-14

LED
on
the
fan
unit
and
its
states
Name Color Status Description
CHECK Amber On Indicates
that
an
error
has
occurred.
Blinking
(*1)
Indicates
that
the
component
requires
maintenance
(This
function
is
also
referred
to
as
the
"locator").
The
LEDs
on
each
component
and
their
statuses
are
as
follows:
Chapter
2

Understanding
the
System
Components 27
