Appendix B
Component Specifications
This appendix provides the specifications of the components.
The components that constitute the SPARC M10-4/M10-4S and the crossbar box are
as follows.
Components that constitute the SPARC M10-4/M10-4S
■
CPU Memory Unit
■
Crossbar Unit
■
Power Supply Unit
■
Fan Unit
■
Internal Disk Drive
■
PCI Express Card
■
Backplanes
■
Operation Panel
B.1 CPU Memory Unit
The CPU memory unit of the SPARC M10-4/M10-4S consists of two units: the upper
unit and lower unit.
The CPU memory unit lower consists of the following components.
■
CPU
■
Memory
■
XSCF
■
PCI Express (PCIe) backplane
The CPU memory unit upper consists of the following components.
■
CPU
■
Memory
CPU and XSCF are directly installed on the CPU memory unit. Thus you cannot
303
