Location number Component
1 CPU memory unit upper
2Side cover
3 Memory
4 PSU backplane unit
5 Fan shelf
6 Fan unit
7 Front cover
8 Internal disk
9Power supply unit
10 Operation panel
11 PCI Express card cassette
12 PCI Express card
13 Crossbar unit mounting frame (*1)
14 Crossbar unit (*1)
15 CPU memory unit lower
16 CMU filler unit
17 Disk filler
18 PCIe
card filler
*1 Not mounted on SPARC M10-4.
