Fujitsu M10-4 - Display Function of the Operation Panel

Location number Component
2 XSCF STANDBY LED
3 CHECK LED
4 BB-ID switch (SPARC M10-4S only)
5 Mode switch
6 Power switch
Table 2-4
Display and operation status of operation panel
LEDs/switches on
operation panel
SPARC M10-4S is master XSCF SPARC M10-4S is not master XSCF
POWER LED Enabled (Indicates the start/stop state of the
SPARC M10-4S)
Enabled (Indicates the start/stop state of the
SPARC M10-4S)
XSCF STANDBY
LED
Enabled (Displays the XSCF status of the
system)
Enabled (Displays the XSCF status of the
SPARC M10-4S)
CHECK LED Enabled (Indicates the SPARC M10-4S error
state)
Enabled (Indicates the SPARC M10-4S error
state)
BB-ID
switch Enabled (Registers a BB-ID number) Enabled (Registers a BB-ID number)
Mode switch (*1) Enabled (Mode operation of the system) Disabled
Power switch Enabled (Start/stop operation of the system) Disabled
*1 Set the same mode for the SPARC M10-4S systems with the master XSCF and the XSCF in the standby state. If the settings are different,
an asterisk (*) is displayed beside the components in the output of the showhardconf or showstatus command.
For a building block configuration, an operation panel is mounted in each chassis of
the SPARC M10-4S. However, the only operation panel on which all of the LEDs and
switches are enabled is that of the chassis housing the master XSCF.
Table 2-4 shows the display and operation status of the
operation panel.
2.3.1 Display function of the operation panel
The operation panel has three LED indicators to implement its display function. The
LED indicators indicate the following. For details, see "2.4.1 Operation panel LEDs."
■
General system status
■
System error warning
■
System error location
