Note
-
The
mode
switch
on
the
operation
panel
does
not
need
to
be
changed
in
active
maintenance.
Remarks
-
For
a
building
block
configuration
with
a
connected
crossbar
box,
switch
the
mode
switches
of
BB-ID#80
and
#81
of
the
crossbar
box.
XSCF>
showpparstatus
-p
0
PPAR-ID

PPAR
Status
00

Running
5.2 Switching
the
Mode
Switch
to
Service
Mode
1.
Switch
the
mode
switch
on
the
operation
panel
to
Service
mode.
For
a
building
block
configuration,
switch
the
mode
switches
of
the
master
chassis
and
those
chassis
(BB-ID#00,
#01)
whose
XSCFs
are
in
the
standby
state
to
Service
mode.
For
details,
see
"2.3.2
Control
function
of
the
operation
panel."
5.3 Checking
the
Operating
Condition
and
Resource
Usage
Status
This
section
describes
the
checking
of
the
operating
condition
of
the
logical
domain
and
the
resource
usage
status
before
maintenance
is
performed
on
each
FRU.
5.3.1 Checking
the
operating
condition
of
the
physical
partition
or
logical
domain
In
the
following
execution
example,
the
operating
condition
of
the
physical
partition
and
logical
domain
is
checked
from
firmware.
1.
Log
in
to
the
XSCF
shell.
2.
Execute
the
showpp arstatus
command
to
confirm
the
operating
condition
of
the
physical
partition.
In
the
following
example,
[PPAR
Status]
of
PPAR-ID
00
displays
"Running",
which
indicates
that
the
physical
partition
is
operating.
Fujitsu
M10-4/Fujitsu
M10-4S/SPARC
M10-4/SPARC
M10-4S
Service
Manual
･
November
201454
