Caution
-
Do
not
connect
the
wrist
strap
clip
to
the
ESD
mat.
By
connecting
the
wrist
strap
clip
to
the
chassis,
the
operator
and
components
have
the
same
level
of
potential,
thus
eliminating
the
danger
of
static
damage.
A
B
How
to
use
a
wrist
strap
Wear
a
wrist
strap
in
such
a
way
that
the
inner
metal
surface
(A
in
the
figure)
of
the
wrist
strap
band
is
in
contact
with
your
skin.
Connect
the
clip
(B
in
the
figure)
directly
to
the
chassis.
Figure
1-4
　　
Wrist
strap
connection
destination
1.6 Other
Precautions
■
Printed
boards
in
the
chassis
can
be
easily
damaged
by
static
electricity.
To
prevent
damage
to
printed
boards,
wear
a
wrist
strap
and
ground
it
to
the
chassis
prior
to
starting
maintenance.
■
When
mounting
any
component
in
the
chassis,
check
the
connectors
on
both
of
the
chassis
and
component
beforehand
to
confirm
that
none
of
the
pins
are
bent
and
that
all
the
pins
are
neatly
arranged
in
lines.
If
a
component
is
mounted
with
a
bent
pin
in
a
connector,
the
chassis
or
component
may
be
damaged.
Also,
carefully
proceed
with
the
work
to
prevent
any
pin
from
being
bent.
