Table 3-2
Whether active maintenance (replacement/addition/removal) is enabled for each FRU (continued)
-: Maintenance cannot be performed.
FRU Single-chassis configuration Building block configuration
Active/hot maintenance Active/hot maintenance Active/cold maintenance
(*6)
PSU backplane unit - - OK
Operation panel - - OK
Crossbar cable (*2) - - -
XSCF BB control cable (*2) - - OK
XSCF DUAL control cable (*2) - - OK
*1 The unit is mounted only in the SPARC M10-4S.
*2 The cable is mounted only in a building block configuration using the SPARC M10-4S.
*3 This is enabled only if the target FRU is in a redundant configuration. For the redundant configuration, we recommend active/hot
maintenance that has a short work
time.
*4 If the target internal disk is the boot device, you cannot use this form of maintenance when the configuration is not a redundant
configuration (RAID configuration). If it is not the boot device, or if even the boot device is redundantly configured, we recommend
active/hot maintenance that has a short
work time.
*5 Perform maintenance work using PCI Hot Plug (PHP). When combined with dynamic SR-IOV and the dynamic reconfiguration
function of PCIe end point devices, PHP enables active maintenance of PCIe cards for which the SR-IOV virtual function and PCIe end
points are assigned to I/O domains.
*6 All FRUs are subject
to this maintenance. It is necessary to use dynamic reconfiguration (DR) to disconnect the chassis requiring
maintenance from the physical partition.
Table 3-3
Whether inactive maintenance (replacement/addition/removal) is enabled for each FRU
-: Maintenance cannot be performed.
FRU Building block configuration
Inactive/hot maintenance Inactive/cold maintenance
CPU memory unit - OK
Memory - OK
Crossbar unit - OK
Power supply unit OK OK
Fan unit OK OK
Internal disk OK OK
3.3 Inactive Maintenance
The type of maintenance performed with the physical partition stopped--the one to
which the chassis requiring maintenance belongs--is referred to as inactive
maintenance. You can perform inactive maintenance only for a system that uses the
SPARC M10-4S in a building block configuration.
Table 3-3 shows whether inactive maintenance is enabled for
each FRU.
Chapter 3 Type of Maintenance 35
