Fujitsu M10-4 - Active Removal

Note -
When removing the SPARC M10-4S chassis from a building block configuration, see
"Chapter 10 Removing a System with a Building Block Configuration" in the Fujitsu
M
10/SPARC M10 Systems Installation Guide.
1. Open rack door
4. Enable removal of a PCIe card for removal
5. Lower cable support
6. Remove PCIe card for removal
7. Fix cable support
8. Confirm that there is no problem with chassis
after removal
9. Close rack door
Removal complete
3. Release assignment of PCIe card
2. Check operating condition of system and
I/O device usage status
- SPARC M10-4S chassis (Note)
7.4.1 Active removal
This section describes the workflows for active/hot and active/cold FRU removal.
References to detailed descriptions are written in the workflow. See any of them as
required. You can perform active/cold removal only for a system with a building
block configuration.
Figure 7-22
Active/hot removal flow (for a PCIe card)
Chapter 7 Maintenance Flow 153
