Fujitsu M10-4 - Cable Connection Ports

(2)
(1)
(3)
Location number Connection port
1 XSCF DUAL control port
2 XSCF BB control port
with the master XSCF, the standby XSCF becomes the master XSCF and continues
the monitoring or control of the system.
Each table has a tag that is used for maintenance recording and management.
2.5.2 Cable connection ports
Figure 2-12 shows the locations of the ports for SPARC M10-4S cable connections. See
the following chapters for the procedures for maintaining the cables:
■
Chapter 14 Maintaining the Crossbar Cables
■
Chapter 16 Maintaining the XSCF BB Control Cables
■
Chapter 17 Maintaining the XSCF DUAL Control Cables
Figure 2-12
Locations of cable connection ports (SPARC M10-4S)
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 201430
