Please
execute
the
following
steps:
1)
Confirm
the
XSCF
STANDBY
LED
of
BB#0
is
not
lit.
2)
Turn
off
the
breaker
of
BB#0.
3)
Remove
BB#0.
4)
Execute
either
the
following:

4-1)
After
the
exchanged
device
is
connected
with
the
system,

turn
on
the
breaker
of
BB#0,
and
please
select
'finish'.

4-2)
If
you
want
to
suspend
the
maintenance
without
exchanging
device,

please
select
'cancel'.
[f:finish|c:cancel]
:
XSCF>
replacefru
------------------------------------------------------------------------------
Maintenance/Replacement
Menu
Please
select
the
chassis
including
replaced
FRU.
　
No.
FRU

Status
---
-------------------
--------------
1

/BB#0

Normal
2

/BB#1

Unmount
3

/BB#2

Unmount
4

/BB#3

Unmount
------------------------------------------------------------------------------
Select
[1-4|c:cancel]
:
1
You
can
now
start
FRU
maintenance.
Do
not
enter
"f"
until
you
complete
the
maintenance
work.
After
replacing
the
FRU,
perform
the
work
in
"6.2.1
Incorporation
of
the
SPARC
M10-4S
chassis
(possible
only
in
a
system
with
a
building
block
configuration)"
to
incorporate
the
FRU
into
the
system.
5.8.2 Releasing
of
the
power
supply
unit
and
fan
unit
of
the
SPARC
M10-4/M10-4S
In
the
following
execution
example,
maintenance
is
performed
on
the
power
supply
unit
(PSU)
of
the
SPARC
M10-4/M10-4S.
1.
Log
in
to
the
XSCF
shell.
2.
Execute
the
replacefru
command
to
display
the
maintenance
menu.
3.
Select
the
FRU
requiring
maintenance
by
specifying
it
with
a
numeric
key.
Since
the
power
supply
unit
(PSU)
of
the
SPARC
M10-4
(BB#0)
is
to
be
maintained,
"1"
is
entered.
4.
Select
the
FRU
requiring
maintenance
by
specifying
it
with
a
numeric
key.
Since
the
power
supply
unit
(PSU)
of
the
SPARC
M10-4
is
to
be
maintained,
"3"
is
entered.
Fujitsu
M10-4/Fujitsu
M10-4S/SPARC
M10-4/SPARC
M10-4S
Service
Manual
･
November
201478
