Table
B-5
　　
Specifications
of
the
internal
disk
drive
(SPARC
M10-4/M10-4S)
Item Description
Maximum
number
of
internal
disk
drives
8
Interface SAS
Location
Front
of
chassis
Type
of
maintenance Active/hot,
active/hot
(using
DR),
inactive/hot,
system-stopped/
hot,
and
system-stopped/cold
Maintenance
category Replacement,
expansion,
and
reduction
Table
B-6
　　
Specifications
of
PCIe
card
(SPARC
M10-4/M10-4S)
Item Description
Maximum
number
of
PCIe
cards
11
(*1)
Location
Rear
of
chassis
Type
of
maintenance Active/hot
(using
PHP),
active/hot
(using
DR),
inactive/hot,
system-stopped/hot,
and
system-stopped/cold
Maintenance
category Replacement,
expansion,
and
reduction
*1
Can
be
mounted
only
on
a
SPARC
M10-4.
For
the
maintenance
procedure,
see
"Chapter
10
Maintaining
the
Internal
Disks."
B.6 PCI
Express
Card
Up
to
eight
PCIe
cards
can
be
mounted
in
a
SPARC
M10-4S
with
a
crossbar
unit
mounted.
For
a
SPARC
M10-4
with
no
crossbar
unit
mounted,
up
to
11
PCIe
cards
can
be
mounted.
Table
B-6
lists
the
specifications
of
the
PCIe
card.
For
the
maintenance
procedure,
see
"Chapter
8
Maintaining
the
PCI
Express
Cards."
B.7 Backplanes
The
backplane
of
the
SPARC
M10-4/M10-4S
is
a
unit
with
connectors
for
connecting
replaceable
units
in
the
chassis.
The
PSU
backplane
unit
of
SPARC
M10-4/M10-4S
mounts
the
memory
that
stores
the
identification
information
and
the
user
setting
information.
　
Fujitsu
M10-4/Fujitsu
M10-4S/SPARC
M10-4/SPARC
M10-4S
Service
Manual
･
November
2014306
