Fujitsu M10-4 - Checking Memory Information

Table 2-3
Memory mounting configurations (CMUL and expanded CMUU)
Number of
memory
modules
Mounted memory
8a in
Figure 2-3
-
16 a in
Figure 2-3
b in
Figure 2-3
------
24 a in
Figure 2-3
b in
Figure 2-3
e in
Figure 2-3
-----
32 a in
Figure 2-3
b in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
----
40 a in
Figure 2-3
b in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
c in
Figure 2-3
---
48 a in
Figure 2-3
b in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
c in
Figure 2-3
d in
Figure 2-3
--
56 a in
Figure 2-3
b in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
c in
Figure 2-3
d in
Figure 2-3
g in
Figure 2-3
-
64 a in
Figure 2-3
b in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
c in
Figure 2-3
d in
Figure 2-3
g in
Figure 2-3
h in
Figure 2-3
XSCF>

showhardconf
------------------------
Omitted
------------------------

BB#00

Status:Normal;

Role:Slav e;

Ver:2003h ;

Serial:2081231002;

+

FRU-Part-Number:CA07361-D202

A1

;

+

Power_Supply_System:Single;

+

Memory_Size:256

GB;

CMUL

Status:Normal;

Ver:0101h;

Serial:PP123002Z4

;

+

FRU-Part-Number:CA07361-D941

A8

;

+

Memory_Size:128

GB;

Type:

B

;

CPU#0

Status:Normal;

Ver:4142h ;

Serial:00010448;

+

Freq:3.700

GHz;

Type:0x20;

+

Core:16;

Strand:2;

CPU#1

Status:Normal;

Ver:4142h ;

Serial:00010418;
Install it by observing the mounting configurations shown in either Table 2-3or Table
2-2.
2.2.2 Checking memory information
Check the type and size of the memory by using the showhardconf command of the
XSCF firmware.
1.
Log in to the XSCF shell.
2.
Execute the show hardconf command to check the memory information.
The capacity and rank of the memory are displayed.
Chapter 2 Understanding the System Components 17
