Table 2-1
Memory mounting configurations (CMUL only)
Number of memory
modules
Mounted memory
8a in Figure 2-3 ---
16 a in Figure 2-3 b in Figure 2-3 --
24 a in Figure 2-3 b in Figure 2-3 e in Figure 2-3 -
32 a in Figure 2-3 b in Figure 2-3 e in Figure 2-3 f in Figure 2-3
Table 2-2
Memory mounting patterns (CMUL and CMUU)
Number of
memory
modules
Mounted memory
8a in
Figure 2-3
-------
16 a in
Figure 2-3
b in
Figure 2-3
------
24 a in
Figure 2-3
b in
Figure 2-3
c in
Figure 2-3
-----
32 a in
Figure 2-3
b in
Figure 2-3
c in
Figure 2-3
d in
Figure 2-3
----
40 a in
Figure 2-3
b in
Figure 2-3
c in
Figure 2-3
d in
Figure
2-3
e in
Figure 2-3
---
48 a in
Figure 2-3
b in
Figure 2-3
c in
Figure 2-3
d in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
--
56 a in
Figure 2-3
b in
Figure 2-3
c in
Figure 2-3
d in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
g in
Figure 2-3
-
64 a in
Figure 2-3
b in
Figure 2-3
c in
Figure 2-3
d in
Figure 2-3
e in
Figure 2-3
f in Figure
2-3
g in
Figure 2-3
h in
Figure 2-3
When only the CPU memory unit lower is mounted
When both the CPU memory unit lower and the CPU memory unit upper
are mounted
When expanding a CPU memory unit upper to a chassis in which only a
CPU memory unit lower is mounted
If you mount memory by expanding a CPU memory unit upper to a chassis in which
only a CPU memory unit lower is mounted, you do not have to remove the memory
mounted on the CPU memory unit lower.
