Fujitsu M10-4 - Removing a CPU Memory Unit

Table 9-5
Memory installation workflow and procedures
Item Maintenance work procedure Reference
1 Accessing the CPU memory unit 9.3.1 Accessing a CPU memory unit
2Removing a CPU memory unit from the
chassis
9.3.2 Removing a CPU memory unit from the chassis
3Removing the CPU memory unit upper
when the target memory is in the CPU
memory unit lower.
9.3.3 Removing the CPU memory unit upper
4 Installing memory
9.7 Installing Memory
5 Installing the removed CPU memory unit
upper
9.8.1 Installing the CPU memory unit upper
6 Installing the CPU memory unit in the
chassis
9.8.2 Installing the CPU memory unit in the chassis
Table 9-6
Memory removal workflow and procedures
Item Maintenance work procedure Reference
1 Accessing the CPU memory unit 9.3.1 Accessing a CPU memory unit
2Removing a CPU memory unit from the
chassis
9.3.2 Removing a CPU memory unit from the chassis
3Removing the CPU memory unit upper
when the target memory is in the CPU
memory unit lower.
9.3.3 Removing the CPU memory unit upper
4Removing memory
9.6 Removing Memory
5 Installing the removed CPU memory unit
upper
9.8.1 Installing the CPU memory unit upper
6 Installing the CPU memory unit in the
chassis
9.8.2 Installing the CPU memory unit in the chassis
9.3 Removing a CPU Memory Unit
This section describes the procedure for removing a CPU memory unit. Enable the
removal of the CPU memory unit before attempting to remove it. For details, follow
the procedure in "Chapter 7 Maintenance Flow."
Unless otherwise specified, the figures explained in this section use the SPARC
M10-4S with a FRAME-A
CPU memory unit.
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014190
