Fujitsu M10-4 - Inactive Removal

1. Open rack door
3. Check operating condition of system and
I/O device usage status
4. Power off chassis requiring maintenance
5. Lower cable support for maintenance on
PCIe card
6. Remove target FRU
7. Secure cable support after maintenance
on PCIe card
8. Diagnose chassis requiring maintenance
10. Return mode switch to original mode
11. Power on chassis requiring maintenance
12. Close rack door
Removal complete
2. Switch mode switch
9. Confirm that there is no problem with chassis
after removal
7.4.2 Inactive removal
This section describes the workflows for inactive/hot and inactive/cold FRU removal.
References to detailed descriptions are written in the workflow. See any of them as
required. You can perform inactive removal work only for a system with a building
block configuration.
Figure 7-25
Inactive/hot removal flow
