Note
-
Confirm
that
the
tab
of
the
PCIe
card
or
the
tab
(A
in
the
figure)
of
the
filler
for
the
PCIe
card
is
inserted
in
the
notch
(B
in
the
figure)
of
the
PCIe
card
cassette.
Figure
8-11
　　
Fixing
the
PCIe
card
filler
8.4 Installing
a
PCI
Express
Card
This
section
describes
the
procedure
for
installing
a
PCIe
card.
8.4.1 Installing
a
PCI
Express
card
1.
Install
the
PCIe
card
by
inserting
it
into
the
connector
of
the
PCIe
card
cassette.
Chapter
8
　
Maintaining
the
PCI
Express
Cards 179
