A
B
Figure 8-12
Installing a PCIe card
2.
Install the bracket for the PCIe card, and secure it with the one screw.
Figure 8-13
Installing the bracket
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014180
