cfgadm

-a
Ap_Id

Type

Receptacle

Occupant

Condition
BB#0-PCI#0

pci-pci/hp

connected

configured

ok
#

cfgadm

-x

led=attn,mode=off

<Ap_Id>
#

svcadm

disable

hotplug
#

cfgadm

-al
Ap_Id

Type

Receptacle

Occupant

Condition
 ＜
Omitted
＞
c2

scsi-sas

connected

configured

6.
If the ATTENTION LED of the target cassette is blinking when you replace the
PCI Express card, turn off the ATTENTION LED.
7.
Assign the I/O device of the incorporated PCI Express card to the logical
domain.
- If you have replaced a faulty PCI Express card, proceed to "Work to
restore a
virtual device."
- If you have added a new PCI Express card:
- If you are using XCP 2230 or later and Oracle VM Server 3.1.1.1 or later:
Perform operations according to the description in "15.3.1 Adding a
physical I/O device to an I/O domain" in the Fujitsu M10/SPARC
M10 Systems
System Operation and Administration Guide.
- If you are using XCP 2221 or earlier or Oracle VM Server 3.1.1 or earlier:
Perform operations according to the description in "3.2.15 Configuring an
I/O device" and "3.2.16 Creating or destroying the SR-IOV virtual function"
in the Fujitsu M10/SPARC M10 Systems
Domain Configuration Guide.
8.
If you have enabled the hotplug service, execute the svcadm command to
disable the hotplug service.
Incorporation of an internal disk
1.
Log in as a super user to Oracle Solaris on the logical domain (control domain
or root domain) into which the target internal disk is to be incorporated.
2.
Execute the cfgadm(1M) command to check the statu s of the incorporated
internal disk.
With the cfgadm -al command, confirm that AP_ID of the
replacement internal
disk has been changed.
Confirm that Occupant shows "configured." If it does not show "configured,"
perform step 3.
Chapter 6 Restoring the System 101
