1. Open rack door
3. Check operating condition of system and
I/O device usage status
4. Stop system
5. Lower cable support for maintenance on
PCIe card
6. Replace faulty FRU
7. Secure cable support after maintenance on
PCIe card
8. Diagnose replaced FRU
10. Return mode switch to original mode
11. Start system
12. Close rack door
Maintenance complete
2. Switch mode switch
9. Confirm that there is no problem with the
replaced FRU
Figure 7-11
System-stopped/hot replacement flow (for an internal disk or PCIe
card)
