1. Open rack door
3. Check operating condition of system and
I/O device usage status
4. Stop system
6. Enable access to FRU requiring maintenance
5. Release chassis requiring maintenance from
system
7. Replace faulty FRU
8. Restore chassis requiring maintenance
9. Incorporate chassis requiring maintenance
into system
12. Return mode switch to original mode
13. Start system
14. Close rack door
Maintenance complete
2. Switch mode switch
11. Confirm that there is no problem with
replaced FRU
10. Diagnose replaced FRU
Figure 7-13
System-stopped/cold replacement flow (for a building block
configuration)
