Fujitsu M10-4 - Page 174

1. Open rack door
3. Check operating condition of system and
I/O device usage status
4. Power off chassis requiring maintenance
5. Release chassis requiring maintenance
from system
6. Enable access to FRU requiring maintenance
9. Incorporate chassis requiring maintenance
into system
8. Restore chassis requiring maintenance
7. Remove target FRU
10. Diagnose chassis requiring maintenance
12. Return mode switch to original mode
13. Power on chassis requiring maintenance
14. Close rack door
Removal complete
2. Switch mode switch
11. Confirm that there is no problem with
chassis after removal
Figure 7-26
Inactive/cold removal flow
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014160
