A
B
C
Figure 9-20
Releasing a connected XSCF board (for SPARC M10-4 with a
FRAME-A CPU memory unit)
-
For the SPARC M10-4S with a FRAME-A/FRA ME-B CPU memory unit
Remove the four screws securing the XSCF board (A in the figure). Then, lift
the right side of the XSCF board to release the connection
of the connector.
