A
Figure
9-26
　　
Screw
for
the
XSCF
mount
(for
the
SPARC
M10-4S
with
a
FRAME-B
CPU
memory
unit)
6.
Remove
the
XSCF
mount.
-
For
the
SPARC
M10-4/M10-4S
with
a
FRAME-A
CPU
memory
unit
Lift
the
protruding
left
lever
(B
in
the
figure)
of
the
XSCF
mount
(A
in
the
figure)
by
about
2
mm
(0.1
in.)
with
your
fingers,
and
slide
it
about
8
mm
(0.4
in.)
toward
the
front
(C
in
the
figure).
Then,
pull
it
upward
to
remove
it
(D
in
the
figure).
Chapter
9
　
Maintaining
the
CPU
Memory
Unit/Memory 209
