A
B
A
B
Note
-
Place
the
removed
CPU
memory
unit
board
on
a
grounded
antistatic
ESD
mat.
(B
in
the
figure).
Figure
9-35
　　
How
to
disconnect
the
connection
of
the
connector
10.
Place
your
thumb
on
the
connector
unit
located
at
the
center
of
the
right
and
left
sides
of
the
CPU
memory
unit
board
(A
in
the
figure)
and
hold
the
board
by
insert ing
your
fingers
under
the
CPU
memory
unit
board
(B
in
the
figure)
from
the
side
of
the
connector
unit.
Fujitsu
M10-4/Fujitsu
M10-4S/SPARC
M10-4/SPARC
M10-4S
Service
Manual
･
November
2014216
