Note -
When replacing the CPU memory unit lower, use the top cover supplied with the new
CPU memory unit lower.
Figure 9-71
Filler unit of the CPU memory unit upper and positions of the clips
on the side guide (for the SPARC M10-4/M10-4S with a FRAME-B
CPU memory unit)
7.
Unlock (push) the top cover of the CPU memory unit and install the cover by
sliding it.
