Note -
When performing active/hot maintenance, at this point wait until the motor stops
rotating (about 1 minute).
Figure 10-3
Knob on internal disk
2.
Hold the lever and pull out the internal disk by about 3 cm (1.2 in.)
Fujitsu M10-4/Fujitsu M10-4S/SPARC M10-4/SPARC M10-4S Service Manual
･
November 2014256
