Note -
Place the removed PSU backplane unit on a grounded antistatic ESD mat.
Figure 13-4
Screws in the fan slot
2.
Loosen the two screws securing the PSU backplane unit and then partia lly
pull out the PSU backplane unit.
Figure 13-5
Screws securing the PSU backplane unit
3.
Pull the PSU backplane unit out a little more. Then, remove the unit by holding
its handle.
