the cable support before starting the work:
- PCI Express card
- CPU memory unit
- Memory
- PSU backplane unit
- Operation panel
- Crossbar unit
1.
Loosen the right and left screws fixing the cable support, and unlock it by
pulling the upper and lower metal fittings towards you (in the direction
of the
arrow).
Figure 5-6
Locations of screws holding the cable support
2.
Lower the cable support.
Chapter 5 Preparations Required for Maintenance 83
