Fujitsu PRIMERGY RX2520 M5 Upgrade And Maintenance Manual

7 Hard disk drive (HDD) / solid
state disk (SSD)
7.1 Safety notes
CAUTION
▶
Before removing several HDD/SSD modules, make sure that all HDD/SSD
modules can be reinstalled into their original bay
. Otherwise, data may be
lost.
▶
Do not touch the circuitry on boards or soldered parts. Hold circuit boards by
their metallic areas or edges.
▶
Before removing an HDD, wait for about 30 seconds until the disk has
stopped spinning completely
.
▶
When an HDD is starting up, a resonant noise may be audible for a short
while. This does not indicate a failure.
▶
Depending on the OS, you can configure the write cache settings for the
HDDs. If a power failure should occur while the write cache is enabled,
cached data may be lost.
▶
When disposing of, transferring, or returning an HDD or SSD, wipe out the
data on the drive for your own security.
▶
Rough handling of HDDs may damage the stored data. To cope with any
unexpected problems, always back up important data. When backing up
data to another HDD, you should make backups on a file or partition basis.
▶
Be careful not to hit the HDD or bring it into contact with metallic objects.
▶
Handle the HDD and SSD on a shock and vibration free surface.
▶
Do not use the HDD and SSD in extremely hot or cold locations, or locations
with extreme temperature changes.
▶
Never attempt to disassemble the HDD or SSD.
▶
For more information, see "Important information" on page 29.
RX2520 M5 Upgrade and Maintenance Manual 123

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
