Installing additional PCIe SSD modules
▶
Remove the dummy locks, see "Removing a 2.5-inch HDD/SSD dummy
module" on page 173
.
▶
Install additional PCIe SSDs, see "Installing a 2.5-inch PCIe SSD module"
on page 181.
The PCIe SSDs are installed in the same frames as the 2.5-inch
HDD/SSD modules.
Concluding steps
▶
"Installing the fan holder" on page 61
.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
Update the server configuration, see "Using the Chassis ID Prom Tool" on
page 94.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
7.5.15 Removing the 4x 2.5-inch PCIe SSD backplane
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
Hard disk drive (HDD) / solid state disk (SSD)
204 Upgrade and Maintenance Manual RX2520 M5
