7 Connector "MLC1" on SAS controller to connector "X1"
8 Connector "MLC2" on SAS controller to connector "X2"
▶
Connect the power cable to connector "X3" on the SAS expander board (9).
Concluding steps
▶
"Installing the fan holder" on page 61
.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
7.5.12 Removing the SAS expander board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
– Hexagon screw driver 5 mm (not valid for Japan)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 197
