12.3.3 Replacing the ODD (2.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No.1 screw driver
Preliminary steps
▶
Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
▶
"Locating the defective server" on page
43.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
▶
"Removing the front panel cage" on page 347.
Removing the defective ODD
▶
Remove the ODD, see "Removing the ODD" on page 300.
Installing the new ODD
▶
Install the ODD, see "Installing the ODD" on page 294.
Concluding steps
▶
"Installing the front panel cage" on page 355.
▶
"Installing the fan holder" on page 61.
▶
"Reassembling" on page 51.
Accessible drives
RX2520 M5 Upgrade and Maintenance Manual 305
