CAUTION
▶
Keep the dummy cover for future use.
▶
If you remove the ODD again and do not replace it with a new one,
the dummy cover must be reinstalled to comply with EMC
regulations and to satisfy cooling requirements and fire protection
measures.
Installing the ODD
Figure 174: Removing the ODD latch
▶
Remove the two screws (see circles).
Accessible drives
294 Upgrade and Maintenance Manual RX2520 M5
