6.4.2 Removing the power distribution board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the crossbar" on page 62.
▶
Remove the PSU from bay 2, see "Removing a hot-plug PSU" on page 110.
Power supply unit (PSU)
RX2520 M5 Upgrade and Maintenance Manual 117
