Fujitsu PRIMERGY RX2520 M5

▶
If applicable, install the SAS expander board, see "Installing the SAS
expander board" on page 193.
▶
Connect the SAS cable to the corresponding controller or to the SAS
expander board.
For the cable plan, see "Appendix B" on page 463
Installing additional HDD/SSD modules
▶
Remove the dummy locks, see
"Removing a 2.5-inch HDD/SSD dummy
module" on page 173
.
▶
Install additional HDD/SSD modules, see "Installing a 2.5-inch HDD/SSD
module" on page 174.
Concluding steps
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
Update the server configuration, see "Using the Chassis ID Prom Tool" on
page 94.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
7.5.10 Upgrading from 16x to 24x 2.5-inch HDD/SSD
configuration
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 191
