Configuring the RAID array, see the documentation of the RAID
controller, used in your configuration, see "Documentation overview" on
page 26.
Concluding steps
No steps needed.
7.5.3 Removing 2.5-inch HDD/SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
PCIe SSDs SFF are installed in the same frames as the 2.5-inch
HDD/SSD modules. Therefore, this section is also valid and applicable if
PCIe SSDs SFF are used.
The preliminary and concluding steps are only necessary for HDD/SSD
modules, not for the PCIe SSDs SFF. PCIe SSDs SFF are never
combined in a RAID array
.
Preliminary steps
▶
If the HDD/SSD module to be removed is combined into a RAID array,
please proceed as follows:
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 175
