Figure 171: Accessible drive in 3.5-inch chassis
1 ODD
Figure 172: Accessible drives in 2.5-inch chassis
1 ODD 2 RDX drive or LTO drive
12.3 Optical disk drive (ODD)
12.3.1
Installing the ODD (2.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No.1 screw driver
Accessible drives
292 Upgrade and Maintenance Manual RX2520 M5
