Fujitsu PRIMERGY RX2520 M5 Upgrade And Maintenance Manual

When the system board is replaced, the settings in the Security tab on
the BIOS setup menu are not automatically transferred, so you must
manually restore the BIOS settings.
The settings related to Security block all data writing in order to prevent
data tampering from external sources such as applications. Restoring
BIOS settings is also blocked according to this specification.
After replacing the front panel or Chassis ID EPROM
▶
Check the SEL log files to verify whether a backup copy of the system board
settings has been transferred to the Chassis ID EPROM, see "Viewing and
clearing the System Event Log (SEL)" on page
85.
Chassis IDPROM: BMC FW backup successful
5.3.3 Updating expansion card firmware
For Japan:
Follow the instructions provided separately.
After replacing the expansion card, it is essential to upgrade the firmware to
the latest version without connecting any storage devices. The latest
expansion card firmware version is available from the Fujitsu support web
pages at:
https://ts.fujitsu.com/support/
For Japan:
https://www.fujitsu.com/jp/products/computing/servers/primergy/downloads/
Note on the boot watchdog
Before updating expansion card firmware, ensure that the boot
watchdog is disabled, see "Disabling the boot watchdog" on page 66
.
After updating expansion card firmware, enable the boot watchdog
again, see "Enabling the boot watchdog" on page 81.
Fujitsu does not assume responsibility for any damage done to the
server or for the loss of any data resulting from firmware updates.
Basic software procedures
RX2520 M5 Upgrade and Maintenance Manual 73

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
