For the cable plan, see "Appendix B" on page 463.
Installing additional HDD/SSD modules
▶
Install additional HDD/SSD modules, see "Installing a 2.5-inch HDD/SSD
module" on page 174
.
Concluding steps
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
Update the server configuration, see "Using the Chassis ID Prom Tool" on
page 94.
▶
"Switching on the server" on page 57.
▶
"Verifying system information backup or restore" on page 72.
▶
Store the system information of your server on the Chassis ID EPROM
integrated into the front panel board. For more information on how to obtain
and use the ChassisId_Prom Tool, see "Using the Chassis ID Prom Tool"
on page 94.
▶
"Resuming BitLocker functionality" on page 88.
7.5.11 Installing the SAS expander board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
–
Hexagon screw driver 5 mm (not valid for Japan)
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 193
