Fujitsu PRIMERGY RX2520 M5 Upgrade And Maintenance Manual

▶
Do not bend or place heavy objects on CDs/DVDs/BDs.
▶
Do not write with ballpoint pen or pencil on the label (printed) side.
▶
Do not attach stickers or similar to the label side. Doing so may cause
rotational eccentricity and abnormal vibrations.
▶
When a CD/DVD/BD is moved from a cold place to a warm place, moisture
condensation on the CD/DVD/BD surface can cause data read errors. In this
case, wipe the CD/DVD/BD with a soft, dry cloth then let it air dry
. Do not dry
the CD/DVD/BD using devices such as a hair dryer
.
▶
To avoid dust, damage, and deformation, keep the CD/DVD/BD in its case
whenever it is not in use.
▶
Do not store CDs/DVDs/BDs at high temperatures. Areas exposed to
prolonged direct sunlight or near heating appliances are to be avoided.
You can prevent damage from the ODD and the CDs/DVDs/BDs, as well
as premature wear of the disks, by observing the following suggestions:
●
Only insert disks in the drive when needed and remove them after
use.
●
Store the disks in suitable sleeves.
●
Protect the disks from exposure to heat and direct sunlight.
3.2.6 Laser information
The ODD complies with IEC 60825-1 laser class 1.
CAUTION
The ODD contains a light-emitting diode (LED), which under certain
circumstances produces a laser beam stronger than laser class 1.
Looking directly at this beam is dangerous.
▶
Never remove parts of the ODD casing!
3.2.7 Modules with Electrostatic-Sensitive Devices
(ESD modules)
ESD modules are identified by the following sticker:
Important information
RX2520 M5 Upgrade and Maintenance Manual 35

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
