Connect the RDX cables to the system board:
1 RDX power cable to connector "PWR ODD"
2 RDX SATA cable to connector "USB3.0 Internal"
For the cable plan, see "Appendix B" on page 463
.
Concluding steps
▶
"Installing the fan holder" on page 61
.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
12.5.2 Removing the RDX drive
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
▶
"Suspending BitLocker functionality" on page
65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
Accessible drives
338 Upgrade and Maintenance Manual RX2520 M5
