Figure 213: Connecting the cables to the RDX drive
▶
Connect the cables to the RDX drive:
1 RDX power cable to connector "RDX PWR"
2 RDX SATA cable to connector "RDX Data"
Figure 214: Connecting the cables to the system board
Accessible drives
RX2520 M5 Upgrade and Maintenance Manual 337
