If applicable, connect the FBU adapter cable.
For the cable plan, see "Appendix B" on page 463.
Concluding steps
▶
"Reassembling" on page
51
.
▶
If applicable, connect all external cables to the expansion card(s).
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
If applicable, "Updating expansion card firmware" on page 73.
▶
If applicable, "Enabling Option ROM scan" on page 74.
▶
"Resuming BitLocker functionality" on page 88.
9.5.2 Removing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Hexagon screw driver 5 mm (not valid for Japan)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 65
.
▶
"Shutting down the server" on page 45.
▶
Remove all external cables from the expansion card to be removed.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
Expansion cards and backup units
236 Upgrade and Maintenance Manual RX2520 M5
