Figure 123: Installing the secondary SFP+ transceiver module
▶
If applicable, install the secondary SFP+ transceiver module accordingly.
9.4.2 Removing SFP+ transceiver modules
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
For Fiber Channel over Ethernet (FCoE) configurations, the ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
A network adapter is equipped with one or two SFP+ (small form-factor
pluggable) transceiver modules. SFP+ transceiver modules are hot-pluggable.
Expansion cards and backup units
226 Upgrade and Maintenance Manual RX2520 M5
