7.5.16 Replacing the 4x 2.5-inch PCIe SSD backplane
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
Remove all PCIe SSD modules from the server, see "Removing a 2.5-inch
PCIe SSD module" on page 183.
CAUTION
▶
Ensure that all PCIe SSD modules are uniquely identified so that
you can reinsert them into their original bays after replacing the
PCIe SSD backplane.
▶
"Getting access to the component" on page
47.
▶
"Removing the air duct" on page
58.
▶
"Removing the fan holder" on page 60.
Removing the defective 4x 2.5-inch PCIe SSD backplane
▶
Remove the PCIe SSD backplane, see "Removing the 4x 2.5-inch PCIe
SSD backplane" on page 205.
Installing the new 4x 2.5-inch PCIe SSD backplane
▶
Install the PCIe SSD backplane, see "Installing the 4x 2.5-inch PCIe SSD
backplane" on page 202.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 207
