4.5.4 Sliding the server into the rack
Figure 8: Sliding the server into the rack
▶
Release the locking mechanism of both rails (1).
▶
Push the server as far as it will go into the rack (2) until the quick-release
levers engage (3).
CAUTION
▶
Be careful with your fingers. You can pinch them when the quick
release levers change to the release position.
▶
Reconnect all cables except the power cord to the server rear
.
Basic hardware procedures
RX2520 M5 Upgrade and Maintenance Manual 55
