Fujitsu PRIMERGY RX2520 M5

Position
Logical drive
number
ServerView RAID Manager display name
one SAS controller
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
[4] 4 Vendor Product (4)
[5] 5 Vendor Product (5)
[6] 6 Vendor Product (6)
[7] 7 Vendor Product (7)
7.5.1.2 Configuration with up to 16 HDD/SSD modules
Figure 82: Configuration with up to 16 2.5-inch HDDs/SSDs
Position
Logical
drive
number
ServerView RAID Manager display name
one SAS controller two SAS controllers
[0] 0 Vendor Product (0) Vendor Product (0:0)
[1] 1 Vendor Product (1) Vendor Product (0:1)
[2] 2 Vendor Product (2) Vendor Product (0:2)
[3] 3 Vendor Product (3) Vendor Product (0:3)
[4] 4 Vendor Product (4) Vendor Product (0:4)
[5] 5 Vendor Product (5) Vendor Product (0:5)
Hard disk drive (HDD) / solid state disk (SSD)
168 Upgrade and Maintenance Manual RX2520 M5
