4.4.4 Removing the top cover
Figure 5: Removing the top cover
▶
Open the locking lever (1). This will slide the top cover back disengaging the
locking mechanism (2).
▶
Remove the top cover (3).
4.5 Reassembling
4.5.1
Safety notes
CAUTION
▶
Before attaching the covers, make sure no unnecessary parts or
tools are left inside the server.
▶
The top cover must be replaced as soon as possible for purposes
of cooling, to comply with EMC regulations (regulations regarding
electromagnetic compatibility) and to prevent fires.
▶
For more information, see "Important information" on page 29
.
Basic hardware procedures
RX2520 M5 Upgrade and Maintenance Manual 51
