12.3.6 Replacing the ODD (3.5-inch chassis)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
Preliminary steps
▶
Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
▶
"Locating the defective server" on page
43.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
▶
"Removing the front panel module" on page 350.
Removing the defective ODD
▶
Remove the ODD, see "Removing the ODD" on page 300.
Installing the new ODD
▶
Install the ODD, see "Installing the ODD" on page 294.
Concluding steps
▶
"Installing the front panel module" on page 354.
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
Accessible drives
