14.3 Removing the serial interface
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: hexagon screw driver 5 mm
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
If applicable, remove the expansion card from slot 4, see "Removing an
expansion card" on page 236.
Removing the serial interface
Figure 251: Removing the serial interface (A)
Serial interface
RX2520 M5 Upgrade and Maintenance Manual 383
